| TECHNICAL DATA | ||
|---|---|---|
| DIMENSIONS | L x W x H (mm) | 1280x800x820 |
| PRODUCT WEIGHT | Vehicle weight in running order (with battery) | 93 kg |
| CYCLING REQUIREMENTS | Maximum Load Applicable age Suitable height Maximum speed Maximum time with one charge |
75 kg 6-14 years old 130-200 cm 20 km/h 30 km |
| VEHICLE PARAMETERS | Working temperature Storage Temperature |
-5-45 degree celcius -5-45 degree celcius |
| BATTERY | Rated Volt Battery capacity Charging voltage Weight |
48 V 576 Wh 57.6 V 15.2 kg |
| MOTOR | Rated power Torque |
750 W 26.6 Nm |
| CHARGER | Input voltage Rated output Voltage Rated current Charging time |
100-240 V 57.6 V 2 A 6-7 hours |
| SUSPENSION | Front /Rear | 2 shock hydraulic absorber with double arms bracket |
| BRAKE | Front Rear |
(x2) Hydraulic single disc φ160 (x2) Hydraulic single disc φ160 |
| TIRE | Size | 16/8-7 |
| FRAME | Materials | High-tensile steel |
| WHEEL BASE | 880 mm | |
| CERTIFICATE | CE |
