| DATA SHEET | ||
|---|---|---|
| DIMENSIONS | L x W x H (mm) FOLD SIZE |
1350x590x1080 1350x320x570 |
| PRODUCT WEIGHT | Vehicle weight in running order (with battery) | 48 Kg |
| CYCLING REQUIREMENTS | Maximum Speed Maximum distance with one charge |
50 Km/h 40 km |
| VEHICLE PARAMETERS | Working temperature Storage Temperature |
-5-45 degree celcius -5-45 degree celcius |
| BATTERY | Rated Volt Battery capacity Charging voltage Weight |
60 V 1200 Wh 67.2 V 8.8 kg |
| MOTOR | Rated power Torque |
2000 W 32 Nm |
| CHARGER | Input voltage Rated output Voltage Rated current Charging time |
100-240 V 67.2 V 3 A 7 hours |
| LIGHT | Headlight Tail light |
LED LED |
| CONTROLLER | Rated Volt Limited current |
48 V 30 A |
| SUSPENSION | Front Rear |
Earless front fork system Double shock absorber |
| BRAKE | Front Rear |
Mechanical disc φ140 Mechanical disc φ140 |
| TIRE | Size | Tubeless 145/70-6 |
| FRAME | Materials | High-tensile steel |
| CERTIFICATE | CE |
